About

About the extension

Projection Sketcher is a SketchUp extension for creating and adjusting projection setup geometry. It is intended for system architects, system designers, and AV engineers.

The extension can use manufacturer-published projector specifications where available and can support manually entered custom projector values. The beta documentation does not guarantee the accuracy or completeness of any projector data.

This product is in the test phase. Verify the accuracy and correctness of results by consulting an AV expert. The tool supports professional design work, but it does not replace professional review.

Authors

Projection Sketcher is created by Dmitry Chelnokov from Cologne, Germany.

This is an image of the author in Cologne, Germany, staying on the Deutzer Bridge with Kranhäuser im Rheinauhafen in the background.

The author has worked with projectors and projection setup design since 2012. The extension grew out of earlier SketchUp Dynamic Component experiments and later Ruby-based extension development.

Support

For issues, documentation feedback, or bug reports, contact:

help@optofinder.de

Use Projection Sketcher: as the first text in the email subject line.

Support languages are English and German. The expected response window is 30 calendar days or less.
